Intel Core i7-12700 (25M Cache // up to 4.90 GHz // 12 Cores) [ BX8071512700 ](2-Years-Warranty)

Essentials

Product Collection

12th Generation Intel® Core™ i7 Processors

Code Name

Products formerly Alder Lake

Vertical Segment

Desktop

Processor Number

i7-12700

CPU Specifications

Total Cores

12

# of Performance-cores

8

# of Efficient-cores

4

Total Threads

20

Max Turbo Frequency

4.90 GHz

Intel® Turbo Boost Max Technology 3.0 Frequency

4.90 GHz

Performance-core Max Turbo Frequency

4.80 GHz

Efficient-core Max Turbo Frequency

3.60 GHz

Performance-core Base Frequency

2.10 GHz

Efficient-core Base Frequency

1.60 GHz

Cache

25 MB Intel® Smart Cache

Total L2 Cache

12 MB

Processor Base Power

65 W

Maximum Turbo Power

180 W

Memory Specifications

Max Memory Size (dependent on memory type)

128 GB

Memory Types

Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s

Max # of Memory Channels

2

Max Memory Bandwidth

76.8 GB/s

Processor Graphics

Processor Graphics

Intel® UHD Graphics 770

Graphics Base Frequency

300 MHz

Graphics Max Dynamic Frequency

1.50 GHz

Graphics Output

eDP 1.4b |  DP 1.4a |  HDMI 2.1

Execution Units

32

Max Resolution (HDMI)

4096 x 2160 @ 60Hz

Max Resolution (DP)

7680 x 4320 @ 60Hz

Max Resolution (eDP – Integrated Flat Panel)

5120 x 3200 @ 120Hz

DirectX Support

12

OpenGL Support

4.5

Multi-Format Codec Engines

2

Intel® Quick Sync Video

Yes

Intel® Clear Video HD Technology

Yes

# of Displays Supported

4

Device ID

0x4680

OpenCL Support

2.1

Expansion Options

Direct Media Interface (DMI) Revision

4

Max # of DMI Lanes

8

Scalability

1S Only

PCI Express Revision

5.0 and 4.0

PCI Express Configurations

Up to 1×16+4 |  2×8+4

Max # of PCI Express Lanes

20

Package Specifications

Sockets Supported

FCLGA1700

Max CPU Configuration

1

Thermal Solution Specification

PCG 2020C

TJUNCTION

100°C

Package Size

45.0 mm x 37.5 mm

Advanced Technologies

Intel® Gaussian & Neural Accelerator

3

Intel® Thread Director

Yes

Intel® Deep Learning Boost (Intel® DL Boost)

Yes

Intel® Optane™ Memory Supported

Yes

Intel® Speed Shift Technology

Yes

Intel® Turbo Boost Max Technology 3.0

Yes

Intel® Turbo Boost Technology

2

Intel® Hyper-Threading Technology

Yes

Intel® Virtualization Technology (VT-x)

Yes

Intel® Virtualization Technology for Directed I/O (VT-d)

Yes

Intel® VT-x with Extended Page Tables (EPT)

Yes

Intel® 64

Yes

Instruction Set

64-bit

Instruction Set Extensions

Intel® SSE4.1 |  Intel® SSE4.2 |  Intel® AVX2

Idle States

Enhanced Intel SpeedStep® Technology

Yes

Thermal Monitoring Technologies

Yes

Intel® Volume Management Device (VMD)

Yes

Security & Reliability

Intel® AES New Instructions

Yes

Secure Key

Yes

Intel® OS Guard

Yes

Execute Disable Bit

Yes

Intel® Boot Guard

Yes

Mode-based Execute Control (MBEC)

Yes

Intel® Control-Flow Enforcement Technology

Yes
